It sits on the standard 0.100" (2.54 mm) pitch — the same grid as legacy 0.100" IDC and DIP socket footprints — so it drops into a familiar board layout without a respin. Rated 5 A per contact at 110 V, with 30.0 µ" (0.76 µm) gold on the mating surface, this is a general-purpose signal interconnect for board-to-board stacking or wire-to-board through a mating receptacle.
Selection note — 12 positions at 0.100" pitch
The 87894-112HLF is the 12-position dual-row variant in the BERGSTIK® II unshrouded header family. Against the 10-position 68602-110HLF and the 14-position 67997-114HLF at the same 0.100" pitch and 30.0 µ" gold plating, the decision is purely position count — match the circuit count on your BOM. The 87894-112HLF carries a 5 A rating; both the 10- and 14-position siblings are rated 3 A. If your load per contact stays under 3 A, either works; above that, the 5 A rating on this 12-position part gives more headroom.
RoHS compliant.
