Push-pull entry, SMT termination
The 89898-304LF: Bottom or top entry with push-pull fastening — the receptacle mates without a latch, so the board stack is held by the friction of the contacts and the alignment of the header pins.
Amphenol ICC (FCI) Dubox receptacle, order code 89898-304LF, 8 positions, dual row, 0.100" (2.54mm) pitch, gold-plated mating contacts, tin-plated solder posts, surface-mount termination, 10.81mm mated stacking height, UL94 V-0.
$1.9800Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | Dubox™ |
| Gender | Female Socket |
| Mounting type | Surface Mount |
| Connector type | Receptacle, Bottom or Top Entry |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Gray |
| Insulation height | 0.275\" (6.99mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Mated stacking heights | 10.81mm |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Box |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Telecommunications |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What compliance documentation does Amphenol ICC (FCI) provide for 89898-304LF?
For RoHS/REACH certification, refer to the manufacturer's compliance documentation available through the distributor.
