919-114J-51SX — Amphenol product photo
Amphenol

Amphenol 919-114J-51SX MCX Plug, 50 Ohm, 6 GHz, RG-405

MPN919-114J-51SX
Active

Amphenol MCX plug, male pin, 50 Ohm, snap-on, for RG-405 (.085"/.086" semi-rigid) cable, gold body, solder termination, 6 GHz, 500 cycles, Bulk.

$12.2200Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

919-114J-51SX Technical Specifications
ParameterValue
Mounting typeFree Hanging (In-Line)
Connector typePlug, Male Pin
Fastening typeSnap-On
Frequency - max6 GHz
Cable groupRG-405 (.085\", .086\" Semi Rigid)
Operating temperature-65°C~165°C
Body materialBrass
Housing colorGold
Dielectric materialPolytetrafluoroethylene (PTFE)
Center contact materialBeryllium Copper
PackageBulk
Impedance50Ohm
Body finishGold
Mating cycles500
Insertion loss0.1dB
Number of ports1
Shield terminationSolder
Contact terminationSolder
Center contact platingGold

Product details

MCX plug for RG-405 semi-rigid – 50 Ohm, 6 GHz ceiling

The 919-114J-51SX: The snap-on coupling gives a positive click on mate and releases with a straight pull — no threads, no tool.

Cable prep and termination – solder both conductors

The connector is free-hanging (in-line) and terminates both the centre conductor and the shield with solder. No crimp tool needed — just a clean square cut on the RG-405, strip the dielectric, tin the centre pin, and flow solder through the shield window.

Active lifecycle — no obsolescence notice or last-time-buy date on file.

Frequently asked questions

What cable type does 919-114J-51SX fit?

This MCX plug is designed for RG-405 (.085" or.086" semi-rigid) coax — the centre conductor and shield are both solder-terminated.
