92417-216HLF — Amphenol product photo
Amphenol

Amphenol FCI 92417-216HLF BERGSTIK II Header, 16 Pos

MPN92417-216HLF
Active

Amphenol FCI BERGSTIK® II, 0.100" (2.54mm) pitch dual-row unshrouded header, 16 positions, through-hole solder, gold-plated phosphor bronze contacts, 5A, UL94 V-0.

$0.8622Ref. price · indicative, final on quote
92417-216HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

92417-216HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions16
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.110\" (2.79mm)
Overall contact length0.530\" (13.46mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.320\" (8.13mm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board-to-board header for standard 0.100" grids

Rated 5A per circuit at 110V, with gold or GXT™ plating at 15.0µin (0.38µm) on the mating surface.

Within the BERGSTIK II series, the 92417-216HLF is a dual-row unshrouded header with all 16 positions loaded. The 0.100" (2.54mm) row spacing matches the pitch, so the footprint is a simple 2x8 grid on 0.100" centers — no staggered holes or oddball keep-outs. Compared to a single-row variant at the same pitch, the dual-row layout doubles the I/O density per linear inch of board edge, which matters when routing a parallel bus or ribbon cable interface.

Frequently asked questions

What is the current rating of 92417-216HLF?

The 92417-216HLF is rated 5A per circuit at 110V. That current rating is typical for a signal/power header at this pitch — enough for on-board power distribution but not bus-level current.

What is the pitch of 92417-216HLF?

The 92417-216HLF uses a 0.100" (2.54mm) pitch on both the pin spacing and the row spacing, matching the standard breadboard-compatible grid.

What is the mating connector for 92417-216HLF?

As an unshrouded header with 0.100" pitch and square pins, the 92417-216HLF mates with standard dual-row female socket strips or IDC receptacles on the same pitch. No specific mating part number is listed, but any 2x8 female connector at 0.100" pitch will fit.
