The Amphenol ICC 92634-150HLF is a 50-position unshrouded male pin header from the BERGSTIK® II series, configured as a through-hole, right-angle board-to-board interconnect. It carries two rows on a standard 0.100" (2.54mm) pitch with matching 0.100" row spacing, so the footprint lands on a familiar 0.100" grid — no special pad layout required. The 30.0µin gold mating finish on phosphor bronze contacts is specified for repeated mating cycles in applications where tin would fret, like test fixtures or modular I/O cards that see field swaps.
Rated 5 A per contact at 110 V, this header suits signal-level and moderate-power distribution on a board. The right-angle orientation places the pin row parallel to the PCB, which keeps the mated stack height low and fits the connector against a board edge or inside a shallow enclosure. Unshrouded means the pins are exposed — the mating receptacle housing provides the polarization and retention, so the board layout must account for the absence of a shroud wall for alignment. The UL94 V-0 black insulation meets the flame-rating requirement for equipment inside an enclosure.
