92634-450HLF — Amphenol product photo
Amphenol

Amphenol 92634-450HLF BergStik II Header, 50 Pos

MPN92634-450HLF
Active

Amphenol BergStik II, Board to Board Header, 92634-450HLF, 50 Positions, 0.100" (2.54mm) Pitch, Through Hole, Right Angle, Tin, 5A, 110V.

$2.2203Ref. price · indicative, final on quote
92634-450HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

92634-450HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions50
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.318\" (8.08mm)
Contact finish - matingTin
Contact length - mating0.318\" (8.08mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

The Amphenol 92634-450HLF is a 50-position, unshrouded BergStik II header built for board-to-board stacking. It runs on the standard 0.100" (2.54 mm) pitch in two rows with the same row spacing, so the footprint matches the classic DIP pattern — no surprises when you drop it into a layout. Rated 5 A per contact at 110 V, with tin-on-tin plating at 100.0 µin on the mating side.

Compared to the 10-position 92634-410HLF, the 50-position 92634-450HLF carries the same 0.100" pitch, same right-angle orientation, and same tin plating — the only decision-relevant difference is the position count.

Frequently asked questions

What is the pitch of 92634-450HLF?

The pitch is 0.100" (2.54 mm) on both the row spacing and the mating interface.

Is 92634-450HLF RoHS compliant?

Yes, the 92634-450HLF is RoHS compliant per the manufacturer's listing.

What is the mounting type of 92634-450HLF?

Through-hole, right-angle — the pins exit parallel to the board for a low-profile mated stack.
