Amphenol ICC (FCI) BergStik II header, order code 93217-212HLF, 12 positions, dual row, 0.100" (2.54mm) pitch, through-hole, unshrouded, male pin, gold or GXT mating finish, solder termination, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.395\" (10.03mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.200\" (5.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 93217-212HLF: It mates with matching socket strips for board-to-board stacking or wire-to-board applications. The housing is rated UL94 V-0.
No direct pin-compatible successor is listed. Availability is confirmed at RFQ; quantities are lot-specific.
The connector carries a UL94 V-0 flammability rating for the black insulation material. RoHS/REACH compliance status should be confirmed at the time of order.
