93217-440HLF, 40-Position 2.54mm BERGSTIK II Header
Amphenol FCI BERGSTIK II, 93217-440HLF, dual-row 40-position unshrouded male pin header, 0.100" (2.54 mm) pitch, through-hole solder termination, push-pull fastening, tin-plated phosphor bronze contacts, insulation height 0.100" (2.54 mm), UL94 V-0, bulk package.
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 40 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.395\" (10.03mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.200\" (5.08mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Frequently asked questions
Where can I buy the 93217-440HLF and what is the lead time?
The 93217-440HLF is sourced to order through independent distribution against an RFQ. Availability and current pricing are confirmed at quote time; no live stock or standard lead time is listed for this obsolete part.
What is the listed style of the 93217-440HLF?
The listed style is Board to Board — this is a header designed for direct board-to-board stacking or mezzanine interconnection.
What series does the 93217-440HLF belong to?
The 93217-440HLF is a member of the BERGSTIK II series, Amphenol FCI's dual-row 0.100" pitch header family.
What compliance ratings does the 93217-440HLF carry?
The insulation body is rated UL94 V-0 for flammability. No RoHS, REACH, or UL safety listing is asserted in the available listing data — confirm current compliance documentation with Amphenol FCI for any new-design or regulatory submission.
