Amphenol ICC (FCI) BERGSTIK® header, breakaway, order code 93689-102-06LF, 6 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, gold GXT™ mating finish, through-hole, press-fit/solder termination.
Amphenol ICC BERGSTIK 93689-102-06LF Header, 6-Pos 2.54mm
MPN93689-102-06LF
Active
Amphenol ICC (FCI) BERGSTIK® header, breakaway, order code 93689-102-06LF, 6 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, gold GXT™ mating finish, through-hole, press-fit/solder termination.
$0.4494Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Press-Fit, Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact finish - post | Tin |
| Contact length - post | 0.177\" (4.50mm) |
| Overall contact length | 0.685\" (17.40mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.399\" (10.13mm) |
| Contact finish thickness - post | 39.4µin (1.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
