93689-105-05LF BERGSTIK® Header, 5 Pos, 0.100" Pitch

MPN93689-105-05LF
Active

Amphenol FCI BERGSTIK® 93689-105-05LF, board-to-board breakaway header, 5 positions, 0.100" (2.54mm) pitch, single row, male pin, press-fit/solder termination, gold GXT™ mating plating 30.0µin (0.76µm), rated 3A per contact, UL94 V-0, -65°C to 125°C.

$0.3448Ref. price · indicative, final on quote
93689-105-05LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

93689-105-05LF Technical Specifications
ParameterValue
SeriesBERGSTIK®
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader, Breakaway
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationPress-Fit, Solder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions5
Contact finish - postTin
Contact length - post0.177\" (4.50mm)
Overall contact length0.608\" (15.44mm)
Contact finish - matingGold, GXT™
Contact length - mating0.327\" (8.30mm)
Contact finish thickness - post39.4µin (1.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

5-position breakaway header, 0.100" pitch, active production

The 93689-105-05LF: It's a board-to-board connector with unshrouded male pins, terminated through-hole via press-fit or solder. Rated 3A per contact, with an operating range from -65°C to 125°C and a UL94 V-0 thermoplastic housing.

The push-pull fastening means it's a friction-fit; no latch, so add a retention method if vibration is present. Termination is through-hole, with a 0.177" (4.50mm) post length for the solder tail. The press-fit option is noted in the spec, but the primary termination is solder — confirm your board hole diameter against the product drawing.
