Amphenol ICC (FCI) BERGSTIK header, order code 93690-105-32, 32 positions, dual row, 0.100" (2.54 mm) pitch, gold GXT™ mating contact finish, through hole, press-fit and solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Press-Fit, Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 32 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.177\" (4.50mm) |
| Overall contact length | 0.608\" (15.44mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.327\" (8.30mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 93690-105-32 is the 32-circuit member of the Amphenol ICC (FCI) BERGSTIK breakaway header line, unshrouded with a push-pull fastening system.
No stock-holding claim — sourced per request.
The 93690-105-32 is available through independent surplus channels.
A functional replacement would require a different part number and board layout — a board spin is required.
