Amphenol ICC (FCI) Bergstik® II, 4-position unshrouded header, 0.100" (2.54 mm) pitch, through-hole right-angle, 30 µinch gold mating finish, 5 A per contact, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 110V |
| Current rating | 5A |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 4 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.160\" (4.06mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 93939-104HLF: The base product number 93939 covers the series; the -104HLF suffix specifies the 4-position, right-angle, gold-plated variant.
Black insulation color aids visual inspection on the board; the 0.190" (4.83 mm) insulation height leaves room for routing traces under the header body.
A direct alternative would be a Bergstik II header with the same 4-position, 0.100" pitch, right-angle layout but with tin plating instead of gold – that variant trades mating cycle life for lower cost. Confirm the plating requirement before swapping.
