FCI BERGSTIK® II 93939-134HLF unshrouded header, 34 positions, 2 rows, 0.100" (2.54mm) pitch, through-hole right-angle, gold mating finish, 5A, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 110V |
| Current rating | 5A |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 34 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.160\" (4.06mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The post tails are tin-plated.
34 positions loaded across two rows at the standard 0.100" x 0.100" grid. The unshrouded design exposes the full pin length.
Through-hole right-angle mounting with a 0.120" (3.05mm) post length and a 0.160" (4.06mm) mating pin length.
