Mating contact finish and current duty
The 94010-122HLF: The phosphor bronze base material carries the rated current; unshrouded headers in this pitch class typically deliver 3 A per contact — confirm the derating curve for the specific application.
Amphenol ICC (FCI) BERGSTIK II header, order code 94010-122HLF, 22 positions, dual row, 0.100" (2.54mm) pitch, unshrouded, through-hole solder termination, push-pull fastening, gold or Gold GXT™ mating plating, UL94 V-0.
$3.2249Ref. price · indicative, final on quote
StockContact for availability
Lead time3-5 Days wk
MOQ1 pcs
- New & original stockTraceable channels only — no mixed lots, no re-taped reels.
- Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
- Photo-verified countsEvery line counted and photographed before the box closes.
- PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 22 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.350\" (8.89mm) |
| Overall contact length | 0.756\" (19.20mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.306\" (7.77mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Who supplies 94010-122HLF and how is it quoted for volume purchases?
Amphenol ICC (FCI) supplies the 94010-122HLF under the BERGSTIK II series. Volume pricing is confirmed at RFQ against the requested quantity.
What compliance documentation does Amphenol ICC (FCI) provide for 94010-122HLF?
RoHS and REACH compliance documentation is available from Amphenol ICC (FCI) upon request.
