Amphenol ICC (FCI) BERGSTIK® II series, 95157-114V, unshrouded header, 14 positions, 0.100" (2.54 mm) pitch, dual-row, surface-mount, gold-plated mating contacts rated 3 A, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 14 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 95157-114V: Terminated by solder to surface-mount pads — no through-holes, which frees routing space on inner layers. Supplied in Tape & Reel with a Pick and Place feature, the part feeds directly into a placement machine without manual handling.
The pitch is 0.100" (2.54 mm) on both rows, with 14 positions loaded in a dual-row configuration. Row spacing is also 0.100" (2.54 mm).
It is unshrouded — there is no plastic shroud around the pins.
