Amphenol ICC (FCI) BERGSTIK® II unshrouded header, 40 positions, 0.100" (2.54 mm) pitch, surface mount, tin-plated male pins, rated 3 A, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 40 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 95157-440LF: Surface mount termination means the part reflows with the board in a single pass — no secondary soldering operation.
Unshrouded headers expose the square pins — no shroud to key or guide the receptacle. The board layout must provide the alignment tolerance; the mating receptacle (typically a BERGSTIK II socket or a standard 0.100" pitch IDC connector) relies on the pin tips for initial alignment.
The tin-plated finish on this part limits mating cycle life — gold plating extends it significantly for field-service or high-reliability builds.
Yes, the listing confirms RoHS compliance.
