Amphenol ICC (FCI) BERGSTIK header, order code 95278-802-26, 26 positions, dual row, 0.100" (2.54mm) pitch, gold GXT™ mating finish, surface mount, solder termination.
Amphenol ICC (FCI) 95278-802-26 BERGSTIK Header, 26-Pos
MPN95278-802-26
Obsolete
Amphenol ICC (FCI) BERGSTIK header, order code 95278-802-26, 26 positions, dual row, 0.100" (2.54mm) pitch, gold GXT™ mating finish, surface mount, solder termination.
$1.1571Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 26 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.315\" (8.00mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
How do I get current pricing and availability for 95278-802-26?
Pricing and availability are confirmed at RFQ. The part is sourced through independent surplus channels; quantities are lot-specific.
What is the closest pin-compatible alternative to 95278-802-26 in this Pin Headers, Sockets & Housings family?
A functional replacement would require a different part number and board layout verification.
