Amphenol ICC (FCI) BergStik® 95293-402-17LF, Board to Board, unshrouded male pin header, 17 circuits, single row, 0.100" (2.54 mm) pitch, surface-mount solder termination, tin-plated phosphor bronze contacts, 3 A, UL94 V-0 black thermoplastic housing, -65°C to 130°C.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 17 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 78.7µin (2.00µm) |
The 95293-402-17LF: Rated 3 A per contact, which is the per-circuit ceiling for signal-level BergStik headers; the temperature rise at full load stays within the housing material limit.
Availability and current pricing confirmed at quote time.
The pitch is 0.100" (2.54 mm) and it is a single-row header with 17 positions.
It is a surface-mount (SMT) termination header.
As an unshrouded male pin header, it mates with standard BergStik or compatible 0.100" pitch single-row female socket strips. The exact mating part number depends on the receptacle style and position count required.
