Board-to-board header, 38 positions, 0.100" pitch
The FCI 95687-438HLF is a 38-position, dual-row, unshrouded male pin header from the BERGSTIK® II series, designed for board-to-board interconnects. It uses a standard 0.100" (2.54mm) pitch on both rows and between rows, matching the legacy DIP footprint that board layout engineers will recognize immediately. All 38 positions are loaded, so the pin count on the BOM line is the circuit count — no partial-population surprises. Rated at 5A per contact with a 110V voltage rating, this header handles signal-level currents and light power distribution. The 5A per contact is typical for a 0.100" pitch header — it's the contact-to-contact spacing, not the pin itself, that limits current here. The tin-on-tin contact finish (100.0µin on the mating side) is suited for applications with a moderate number of mating cycles, not for frequent reconnection in a corrosive environment. The housing is rated UL94 V-0, so it meets the flame-retardancy requirement for equipment inside an enclosure. Through-hole solder termination gives a reliable mechanical anchor on the PCB.
Sourcing and lifecycle
RoHS compliance is standard for this series, matching the lead-free assembly requirements of most production lines today.
Mating and fit
As an unshrouded header, this part mates with any standard 0.100" pitch dual-row receptacle or socket strip that accepts 0.025" square pins. The push-pull fastening type means no locking latch — the retention comes from the contact friction alone, which is fine for internal board stacks where the assembly is not subject to vibration or cable strain. The 0.360" (9.14mm) mating pin length and 0.820" (20.83mm) overall length give enough reach to mate with a standard receptacle through a board-to-board stack.
