Amphenol ICC (FCI) BERGSTIK® series, 98401-101-28LF: board-to-board unshrouded breakaway header, 28 positions, 2 rows, 0.100" (2.54 mm) pitch, surface mount, gold GXT™ mating finish, 3 A per contact, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C ~ 130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.084\" (2.14mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Features | Board Guide |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 28 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 98401-101-28LF: The surface-mount termination and 0.084" (2.14 mm) insulation height keep the profile low on the board, useful for mezzanine stacking where z-height is tight. Board guide features assist alignment during assembly.
In a 28-position header, total current per row is limited by the sum of contact currents and the board trace width; derate above 85°C ambient per the standard connector derating curve.
