Amphenol ICC (FCI) BERGSTIK header, order code 98401-402-26, 26 positions, dual row, 0.100" (2.54 mm) pitch, tin-lead mating and post contacts (150.0 µ"), surface-mount, solder termination, unshrouded, push-pull fastening.
Amphenol ICC (FCI) 98401-402-26 BERGSTIK Header, 26-Pos
MPN98401-402-26
Obsolete
Amphenol ICC (FCI) BERGSTIK header, order code 98401-402-26, 26 positions, dual row, 0.100" (2.54 mm) pitch, tin-lead mating and post contacts (150.0 µ"), surface-mount, solder termination, unshrouded, push-pull fastening.
$4.4200Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.084\" (2.14mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
All specifications
| Parameter | Value |
|---|---|
| Features | Board Guide |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 26 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Tin-Lead |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 150.0µin (3.81µm) |
Product details
Frequently asked questions
What compliance documentation does Amphenol ICC (FCI) provide for the 98401-402-26?
No RoHS or REACH compliance statements are on record for this part.
