Amphenol ICC (FCI) BERGSTIK header, order code 98401-802-46LF, 46 positions, dual row, 0.100" (2.54 mm) pitch, 3 A, gold GXT mating contacts, surface-mount, unshrouded breakaway.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.084\" (2.14mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Features | Board Guide |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 46 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - post | 150.0µin (3.81µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 98401-802-46LF is the 46-circuit member of Amphenol ICC (FCI)'s BERGSTIK breakaway header line, dual-row, unshrouded.
UL94 V-0 thermoplastic body, operating range -65°C to 130°C, board guide feature included.
The BERGSTIK series carries UL94 V-0 flammability rating on the thermoplastic housing. RoHS and REACH compliance data is available from the manufacturer upon request.
