2.00mm Pitch, 16-Position Right-Angle Header
The 0.157" (4.00mm) mating pin length gives a solid wipe inside the receptacle, and the 0.098" (2.50mm) post length fits standard 1.6mm PCBs with enough tail for a reliable solder fillet.
Right-Angle Routing and Board Fit
Through-hole right-angle mounting places the pins perpendicular to the board edge, useful for mezzanine or parallel-PCB stacks where the header sits at the board perimeter. The 0.157" (4.00mm) insulation height sets the clearance under the housing — keep this in mind when routing traces under the body on the top layer. No shrouding or keying — the push-pull fastening means the mating receptacle aligns by the pin pattern alone.
The base product number is 98423, and the part ships in bulk.
