98424-F52-06ALF — Amphenol product photo
Amphenol

98424-F52-06ALF Minitek 2.00mm Header SMT 6 Pos 2A

MPN98424-F52-06ALF
Active

Amphenol ICC (FCI) Minitek® 2.00mm, 6-circuit, 2-row shrouded header, SMT, gold flash mating, latch holder, 2 A / 200 V, UL94 V-0

$1.2300Ref. price · indicative, final on quote
98424-F52-06ALF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

98424-F52-06ALF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typeLatch Holder
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorCream
Insulation height0.244\" (6.20mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageTape & Reel (TR); Cut Tape (CT)
FeaturesKeying Slot, Pick and Place
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions6
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact finish - matingGold
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - matingFlash

Product details

The 98424-F52-06ALF is a 6-position, 2-row, shrouded male pin header from the Minitek® 2.00mm series, terminated by SMT to the board. Flash plating is a thin gold layer — it gives a corrosion-resistant interface for moderate mating cycles (think a few hundred mates over the product life), not the thousands you'd spec with 30 µinch gold.

6 Positions vs 4 or 18 — Which One Fits Your BOM

The 98424-F52-06ALF is the 6-position member of the Minitek 2.00mm SMT header family. No functional second-source exists — the 98424 base number is Amphenol ICC (FCI) only.

Frequently asked questions

Where can I buy 98424-F52-06ALF and get current pricing?

No on-shelf stock is claimed; availability is verified per inquiry.
