Molex 98464-G61-06LF Header 6-pos 2.00mm
MPN98464-G61-06LF
Active
Molex Minitek® 2.00mm 98464-G61-06LF, 6-position dual-row male header, 0.079" (2.00mm) pitch, right-angle through-hole, 200 V (AC/DC), 2 A per circuit, gold GXT™ mating / tin solder-side plating, UL94 V-0, bulk.
$2.3700Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Cream |
| Insulation height | 0.240\" (6.10mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Features | Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 6 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Frequently asked questions
How do I source 98464-G61-06LF and get a quote?
The part is quoted to order against the BOM quantity through independent distribution — request a quote to confirm availability and current pricing for your required volume.
What is the mating half for 98464-G61-06LF?
The header mates with the matching Minitek 2.00mm dual-row receptacle in the same series; the keying slot must align with the corresponding notch in the receptacle housing to prevent mis-orientation.
What is the current and voltage rating?
Rated 2 A per circuit and 200 V (AC/DC) — suitable for signal-level and low-current DC duties in board-to-board or cable interconnects.
