MUSB-A511-00 — Amphenol product photo
Amphenol

Amphenol MUSB-A511-00 USB-A Receptacle, IP67, Panel Mount

MPNMUSB-A511-00
Active

Amphenol ICC MUSB series USB-A receptacle, order code MUSB-A511-00, 4 contacts, 1.5 A, IP67, shielded, gold-plated contacts, panel mount through-hole, solder termination, board lock.

$9.9700Ref. price · indicative, final on quote
MUSB-A511-00 datasheet
StockIn Stock (22)
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

MUSB-A511-00 Technical Specifications
ParameterValue
SeriesMUSB
Mounting typePanel Mount, Through Hole
Connector typeUSB-A (USB TYPE-A)
Current rating1.5A
Positions4
Ingress protectionIP67 - Dust Tight, Waterproof
Mounting featureFlange, Vertical
Operating temperature-40°C~105°C
Insulation colorBlack
Shell (Shielding material)Copper Alloy
Material flammability ratingUL94 V-0
GenderReceptacle
PackageBulk
FeaturesBoard Lock
ShieldingShielded
TerminationSolder
Mating cycles1500
Contact finishGold
SpecificationsUSB 2.0
Number of ports1

Product details

Panel-mount USB-A with IP67 seal and board lock

The MUSB-A511-00 is a USB 2.0 Type-A receptacle in Amphenol ICC's MUSB series, designed for panel-mount through-hole installation with a vertical flange. Rated 1.5 A per contact, the gold-plated contacts and shielded copper-alloy shell are sealed to IP67 when mated, with a UL94 V-0 rated housing and 1500 mating cycles.

Board lock retention and 1500-cycle contact system

Integrated board locks hold the receptacle during reflow and resist shear from cable strain, while the gold-over-nickel contact finish supports 1500 mating cycles without signal degradation. The shielded copper-alloy shell provides EMI containment for USB 2.0 data rates, and the IP67 seal keeps the interface dust-tight and waterproof in outdoor or washdown environments.
