Amphenol ICC MUSB USB mini-B receptacle, order code MUSBB15130, 5 contacts, 1 A, USB 2.0, IP67, shielded, gold-plated contacts, panel mount through-hole right-angle, solder termination.
| Parameter | Value |
|---|---|
| Series | MUSB |
| Mounting | Panel Mount, Through Hole, Right Angle |
| Connector type | USB - mini B |
| Current rating | 1A |
| Positions | 5 |
| IP rating | IP67 - Dust Tight, Waterproof |
| Mounting feature | Flange, Horizontal |
| Operating temperature | -40°C~105°C |
| Insulation color | Black |
| Shell (Shielding material) | Copper Alloy |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
| Parameter | Value |
|---|---|
| Package | Box |
| Shielding | Shielded |
| Termination | Solder |
| Mating cycles | 5000 |
| Contact finish | Gold |
| Specifications | USB 2.0 |
| Number of ports | 1 |
The MUSBB15130 is the IP67-rated, shielded USB mini-B receptacle in Amphenol ICC's MUSB series, carrying 5 contacts for USB 2.0 signal and power. Gold-plated contacts are rated 1 A per circuit, and the receptacle withstands 5000 mating cycles — the plating and seal suit field-serviceable panel ports in industrial or outdoor equipment.
The MUSBB15130 is a USB mini-B receptacle (female) with 5 contacts, shielded, and rated for USB 2.0.
RoHS and REACH compliance documentation is available from the manufacturer upon request.
