Aries Electronics — Pin Headers, Sockets & Housings

Aries Electronics Pin Headers, Sockets & Housings — 4 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
12-0511 · 14-0600 · 14-823 · 12-7350
Termination Post Length
0.150" (3.81mm) · 0.145" (3.68mm) · 0.420" (10.67mm) · 0.690" (17.52mm)
Number of Positions or Pins (Grid)
12 (1 x 12) · 14 (2 x 7) · 14 (1 x 14) · 22 (2 x 11)
Operating Temperature
-55°C ~ 105°C · - · -55°C~105°C · -55°C~125°C
Contact Finish Thickness - Mating
50.0µin (1.27µm) · 10.0µin (0.25µm) · 200.0µin (5.08µm) · 30.0µin (0.76µm)
Housing Material
Polyamide (PA46), Nylon 4/6, Glass Filled · Polyamide (PA46), Nylon 4/6 · Polyamide (PA), Nylon, Glass Filled · Polyphenylene Sulfide (PPS)
Mounting Type
Through Hole · Through Hole, Right Angle, Horizontal · Through Hole, Right Angle · Surface Mount
Type
SIP · DIP, 0.3" (7.62mm) Row Spacing · DIP, 0.2" (5.08mm) Row Spacing · PGA, ZIF (ZIP)
