CUI Devices CDM814-06A-MT-F810-67
MPNCDM814-06A-MT-F810-67
Active
6 PINS, PANEL MOUNT, CRIMPED PC
$9.5600Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCDM814
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CDM814 |
| Mounting | Panel Mount |
| Connector type | Plug, Male Pins |
| Fastening type | Threaded |
| Voltage rating | 30V |
| Current rating | 1.5A |
| IP rating | IP67 - Dust Tight, Waterproof |
| Mounting feature | Bulkhead - Front Side Nut |
| Operating temperature | -25°C ~ 80°C |
| Color | Silver |
| Shell material | Brass |
| Insert material | Polyamide (PA66), Nylon 6/6 |
All specifications
| Parameter | Value |
|---|---|
| Contact material | Brass |
| Primary material | Metal |
| Material flammability rating | UL94 V-0 |
| Package | Box |
| Shielding | Unshielded |
| Orientation | A |
| Termination | Solder Cup |
| Shell finish | Nickel |
| Positions | 6 |
| Shell size - insert | M8-6 |
| Contact finish - mating | Gold |
