CUI Devices SJ-3554A-SMT-TR-67
MPNSJ-3554A-SMT-TR-67
Active
STEREO JACK IP67 3.5 5 CONDUCTOR
$2.1604Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesSJ
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | SJ |
| Mounting | Surface Mount, Right Angle |
| Connector type | Phone Jack |
| Voltage - rated | 12VDC |
| Current rating | 1 A |
| Operating temperature | -30°C~85°C |
| Body color | Black |
| Contact material | Copper Alloy, Titanium (Ti) |
| Housing material | Polyamide (PA6T), Nylon 6T |
| Mating length (Depth) | 0.551\" (14.00mm) |
| Contact material - plating | Gold |
| Gender | Female |
All specifications
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Board Guide, IP67 |
| Shielding | Unshielded |
| Termination | Solder |
| Signal lines | 5 Conductor (TRRRS) |
| Actual diameter | 0.142\" (3.60mm) |
| Internal switch | Does Not Contain Switch |
| Number of positions (Contacts) | 5 Conductors, 5 Contacts |
| Industry recognized mating diameter | 3.50mm (0.141\", 1/8\", Mini Plug) - Headphone |
