CUI Devices phone plug, order code SP-2533A, male, 3 conductors (TRS), 2.50 mm industry recognized mating diameter, 1 A, 12 VDC, nickel-plated contacts, crimp termination, free hanging, unshielded, includes cover.
| Parameter | Value |
|---|---|
| Mounting | Free Hanging (In-Line) |
| Connector type | Phone Plug |
| Voltage - rated | 12VDC |
| Current rating | 1 A |
| Cable opening | 0.154\" (3.90mm) |
| Operating temperature | -25°C~70°C |
| Body color | Silver, Black |
| Body material | Brass |
| Contact material | Brass |
| Housing material | Acrylonitrile Butadiene Styrene (ABS) |
| Insulation color | Black |
| Mating length (Depth) | 0.433\" (11.00mm) |
| Parameter | Value |
|---|---|
| Contact material - plating | Nickel |
| Gender | Male |
| Package | Bag |
| Features | Cover |
| Includes | 2 pcs - 1 Connector, 1 Cover |
| Shielding | Unshielded |
| Termination | Crimp |
| Signal lines | Stereo (3 Conductor, TRS) |
| Actual diameter | 0.091\" (2.30mm) |
| Internal switch | Does Not Contain Switch |
| Number of positions (Contacts) | 3 Conductors, 3 Contacts |
| Industry recognized mating diameter | 2.50mm (0.094\", 3/32\", Sub Mini, Miniature) - Headphone |
The SP-2533A is a male 2.50 mm phone plug from CUI Devices, accepting 3 conductors (TRS) for stereo audio signals. It terminates via crimp and mounts free-hanging (in-line) with a cable opening of 0.154" (3.90 mm). Rated 1 A at 12 VDC, with nickel-plated brass contacts and a brass body. The ABS housing is black; the cover is silver and black. Includes 2 pieces — 1 connector and 1 cover.
Male phone plug, 2.50 mm industry recognized mating diameter, 3 conductors (TRS).
