Amphenol ICC (FCI) BERGSTIK® header, order code 77317-812-68LF, 68 positions, dual row, 0.100" (2.54 mm) pitch, 3 A per contact, gold GXT™ mating contacts, through-hole right-angle, solder termination.
77317-812-68LF Amphenol ICC BERGSTIK® Header 68-Pos 2.54mm
MPN77317-812-68LF
Active
Amphenol ICC (FCI) BERGSTIK® header, order code 77317-812-68LF, 68 positions, dual row, 0.100" (2.54 mm) pitch, 3 A per contact, gold GXT™ mating contacts, through-hole right-angle, solder termination.
$3.6198Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header, Breakaway |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C ~ 130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 68 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.268\" (6.80mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
Product details
Frequently asked questions
What compliance documentation does Amphenol ICC (FCI) provide for 77317-812-68LF?
RoHS and REACH compliance documentation is available from the manufacturer upon request.
