Greenconn CWFB201-2001A001K2SC
MPNCWFB201-2001A001K2SC
Active
2.00MM PITCH CONNECTOR
$2.43Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesCWFB201
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | CWFB201 |
| Type | Female Socket |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation material | Polybutylene Terephthalate (PBT) |
| Style | Board to Board |
| Package | Tube |
| Features | Solder Retention |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 40 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
