HARTING — Wire-to-Board Connectors

HARTING Wire-to-Board Connectors — 4 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Positions Per Level
2 · 3 · 4 · 5
Wire Gauge
- · 20-24 AWG · 20-26 AWG · 16-30 AWG
Current
6 A · 10 A · 12 A · 13.5 A
Pitch
0.100" (2.54mm) · 0.138" (3.50mm) · 0.150" (3.81mm) · 0.197" (5.00mm)
Screw Thread
- · M2 · M3 · M4
Torque - Screw
- · 0.2-0.25 Nm (1.7-2.2 Lb-In) · 0.5-0.6 Nm (4.4-5.3 Lb-In) · 1.2-1.5 Nm (10.6-13.3 Lb-In)
Housing Material
Liquid Crystal Polymer (LCP) · Liquid Crystal Polymer (LCP), Glass Filled · Polyamide (PA), Nylon · Polyamide (PA), Nylon, Polyphthalamide (PPA)
Voltage
160 V · 300 V · 400 V · 600 V
