HARTING — Pin Headers, Sockets & Housings

HARTING Pin Headers, Sockets & Housings — 16 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Number of Positions
4 · 9 · 6 · 10
Insulation Height
0.579" (14.70mm) · 0.494" (12.55mm) · 0.335" (8.51mm) · 0.350" (8.89mm)
Positions Per Level
2 · 3 · 5 · 6
Contact Length - Post
0.118" (3.00mm) · 0.189" (4.80mm) · 0.114" (2.90mm) · 0.177" (4.50mm)
Color
Red · Blue · Black · White
Contact Length - Mating
- · 0.240" (6.10mm) · 0.228" (5.80mm) · 0.242" (6.15mm)
Insulation Material
Polyamide (PA), Nylon · Polybutylene Terephthalate (PBT), Glass Filled · - · Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Pitch
0.264" (6.70mm) · 0.100" (2.54mm) · 0.197" (5.00mm) · 0.200" (5.08mm)
