100-position 0.50 mm pitch right-angle plug for dense mezzanine stacks
Board-stacking height and footprint fit
This mid-height profile fits between the ultra-low 3 mm stacks and taller 6-8 mm mezzanines, giving clearance for mid-board components on the opposing side. The 0.50 mm pitch demands careful trace fan-out — expect to route on inner layers or use micro-vias if the BGA-style escape pattern is tight. The 2-row arrangement keeps the connector body narrow, but the 100 positions still require a board footprint roughly 25 mm long.
RoHS compliant per JST's declaration, which covers EU directive requirements for solderable assemblies. Supplied in Tape & Reel (TR) packaging, compatible with automated pick-and-place assembly.
