JST Sales America Inc. FMN FFC connector, order code 16FMN-BMTTR-A-TB(LF)(SN), 16 positions, 1.00 mm pitch, 0.5 A, 50 V, tin-plated contacts, surface-mount vertical, solder termination.
| Parameter | Value |
|---|---|
| Series | FMN |
| Mounting type | Surface Mount |
| Cable end type | Straight |
| Flat flex type | FFC |
| Connector (Contact type) | Contacts, Vertical - 1 Sided |
| Voltage rating | 50V |
| Current rating | 0.5A |
| Operating temperature | -25°C~85°C |
| Housing color | Black |
| Contact material | Phosphor Bronze |
| Housing material | Polyamide (PA6T), Nylon 6T |
| Height above board | 0.201\" (5.10mm) |
| Material flammability rating | UL94 V-0 |
| Pitch | 0.039\" (1.00mm) |
| Package | Tape & Reel (TR); Cut Tape (CT) |
| Features | Low Insertion Force (LIF) |
| Termination | Solder |
| Contact finish | Tin |
| FFC, FCB thickness | 0.30mm |
| Positions | 16 |
The 16FMN-BMTTR-A-TB(LF)(SN) is the 16-circuit member of JST's FMN series of vertical FFC connectors. It accepts 0.30 mm thick FFC, mates with contacts on one side, and uses a low-insertion-force (LIF) design for hand assembly without a tool.
The 16FMN-BMTTR-A-TB(LF)(SN) is available in Tape & Reel or Cut Tape packaging. Request a quote for current pricing and lead time.
