JST JMC 40RF-JMCS-G-1B-TF(N)(LF)(SN)

MPN40RF-JMCS-G-1B-TF(N)(LF)(SN)
Obsolete

JST JMC series, 40-position FFC/FPC receptacle, 0.020" (0.50mm) pitch, dual-row, gold-plated contacts, surface mount, 3.30mm height above board, board guide and solder retention features.

$1.8500Ref. price · indicative, final on quote
40RF-JMCS-G-1B-TF(N)(LF)(SN) datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

40RF-JMCS-G-1B-TF(N)(LF)(SN) Technical Specifications
ParameterValue
SeriesJMC
Mounting typeSurface Mount
Connector typeReceptacle, Center Strip Contacts
Height above board0.130\" (3.30mm)
Pitch0.020\" (0.50mm)
PackageTape & Reel (TR) Cut Tape (CT)
FeaturesBoard Guide, Solder Retention
Contact finishGold
Rows2
Positions40

Product details

FFC/FPC Receptacle for Fine-Pitch Board Interconnects

The JST 40RF-JMCS-G-1B-TF(N)(LF)(SN) is a 40-position FFC/FPC receptacle from the JMC series, using a 0.020" (0.50mm) pitch dual-row contact layout. It is a surface-mount connector with gold-plated center strip contacts, designed for flex-circuit or flat-flexible-cable termination.

No direct replacement order code is listed in the lifecycle record.

The 0.50 mm pitch places this connector in fine-pitch FPC territory. The dual-row arrangement packs 40 circuits into a narrow body, which suits high-density signal routing in compact handheld or display assemblies.

Frequently asked questions

Is 40RF-JMCS-G-1B-TF(N)(LF)(SN) obsolete?

Yes, the JST 40RF-JMCS-G-1B-TF(N)(LF)(SN) is officially obsolete.

What is the pitch of 40RF-JMCS-G-1B-TF(N)(LF)(SN)?

The pitch is 0.020" (0.50mm), a fine-pitch spacing typical for FFC/FPC interconnects. The dual-row arrangement gives 40 positions in a compact footprint.

Where can I buy 40RF-JMCS-G-1B-TF(N)(LF)(SN)?

This obsolete part is available through independent distribution.
