B13B-EH-A(LF)(SN) — JST product photo
JST

JST B13B-EH-A(LF)(SN) EH Header 13 Pos 2.5mm Pitch

MPNB13B-EH-A(LF)(SN)
Active

JST EH series, 13-position single-row shrouded header, 2.50 mm pitch, through-hole, tin-plated contacts, 3 A, 250 V, UL94 V-0, RoHS.

$0.5300Ref. price · indicative, final on quote
B13B-EH-A(LF)(SN) datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

B13B-EH-A(LF)(SN) Technical Specifications
ParameterValue
SeriesEH
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typeFriction Lock
Voltage rating250V
Current rating3A
Operating temperature-25°C~85°C
Contact materialBrass
Insulation colorNatural
Insulation height0.236\" (6.00mm)
Insulation materialPolyamide (PA66), Nylon 6/6
Mated stacking heights8.1mm
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 3 Wall
TerminationPress-Fit, Solder
Contact shapeSquare
Rows1
Pitch0.098\" (2.50mm)
Positions13
Contact finish - postTin
Contact length - post0.126\" (3.20mm)
Contact finish - matingTin
Contact length - mating0.130\" (3.30mm)

Product details

The B13B-EH-A(LF)(SN): This 13-position single-row header uses a 2.50 mm pitch, which sets the board footprint for routing traces between the pins. The 0.098" spacing is standard for signal-level wire-to-board interconnects and matches the JST EH series receptacle housing. The through-hole termination with a 3.20 mm post length gives a solid solder joint on the PCB, and the 6.00 mm insulation height leaves clearance for mating the receptacle without interference from nearby components.

Current and Voltage Ceiling for Signal Duty

The 3 A rating keeps the temperature rise within the nylon 6/6 housing limits at 85°C ambient.

Mates with JST EH series crimp receptacle housings (e.g., EHR-13) using the matching crimp terminal (SEH-001T-P0.6 or equivalent).

Frequently asked questions

What is the mating connector for JST B13B-EH-A?

The mating half is a JST EH series crimp receptacle housing, such as the EHR-13, loaded with SEH-001T-P0.6 crimp terminals. The friction lock on the header aligns with the receptacle ramp for retention.
