JST B14B-PHDSS(LF)(SN) Header – 14 Pos, 2 mm Pitch

MPNB14B-PHDSS(LF)(SN)
Active

JST PHD series, Board to Cable/Wire, Header, Male Pin, 14 Positions, 2.00 mm Pitch, Through Hole, Solder, Tin Contacts, UL94 V-0, 3 A, 250 V

$0.6300Ref. price · indicative, final on quote
B14B-PHDSS(LF)(SN) datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

B14B-PHDSS(LF)(SN) Technical Specifications
ParameterValue
SeriesPHD
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typeDetent Lock
Voltage rating250V
Current rating3A
Operating temperature-25°C~85°C
Contact materialCopper Alloy
Insulation colorNatural
Insulation height0.256\" (6.50mm)
Insulation materialPolyamide (PA), Nylon, Glass Filled
Mated stacking heights8.8mm
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions14
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.118\" (3.00mm)
Overall contact length0.291\" (7.40mm)
Contact finish - matingTin
Contact length - mating0.114\" (2.90mm)

Product details

14-Position Shrouded Header for Wire-to-Board Harnesses

The detent lock provides an audible click on full engagement, confirming the mating half is seated and reducing the chance of partial connection under vibration.

The mated stack height of 8.8 mm gives a low-profile interconnect for space-constrained enclosures. The through-hole termination anchors the header to the board, handling the shear force from cable strain during assembly and service.

The 14-position B14B-PHDSS(LF)(SN) sits between the 12-position B12B-PHDSS(LF)(SN) and the 16-position B16B-PHDSS. All use the same shrouded header design and tin-plated contacts, so the board footprint scales linearly with position count. For a 14-circuit harness, this header matches the pin count exactly — no unused positions. If the BOM calls for 16 circuits, the B16B-PHDSS is the direct step-up, identical in every other spec.
