JST S12B-XADSS-N(LF)(SN) 12-Position 2.50mm Header, Active

MPNS12B-XADSS-N(LF)(SN)
Active

JST XAD series, 12-position, 2-row, 0.098" (2.50mm) pitch, shrouded header, male pin, through hole right angle, locking ramp, tin contacts, UL94 V-0, active

$1.6900Ref. price · indicative, final on quote
S12B-XADSS-N(LF)(SN) datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

S12B-XADSS-N(LF)(SN) Technical Specifications
ParameterValue
SeriesXAD
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typeLocking Ramp
Voltage rating250V
Current rating3A
Operating temperature-25°C~85°C
Contact materialCopper Alloy
Insulation colorNatural
Insulation height0.476\" (12.10mm)
Insulation materialPolyamide (PA66), Nylon 6/6, Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Cable/Wire
PackageBulk
ShroudingShrouded - 4 Wall
TerminationSolder
Contact shapeCircular
Rows2
Pitch0.098\" (2.50mm)
Positions12
Row spacing - mating0.098\" (2.50mm)
Contact finish - postTin
Contact length - post0.134\" (3.40mm)
Contact finish - matingTin

Product details

12-position dual-row 2.50mm pitch header with locking ramp

Right-angle through-hole with tin-plated contacts

The header is mounted through-hole, right-angle — the pins exit the bottom of the insulator at 90° to the mating face. The 0.134" (3.40mm) post length is long enough for a standard 1.6mm board with a good solder fillet on the bottom side.

Rated 3A per contact at 250V, UL94 V-0 housing

Each contact is rated 3A at 250V. The 3A figure is per circuit at the rated temperature — if you're running all 12 positions at current, the total heat is within the housing's thermal budget.

Frequently asked questions

What is the mating connector for S12B-XADSS-N(LF)(SN)?

This header mates with a JST XAD series receptacle housing that accepts crimp terminals. The locking ramp on the header engages with the receptacle's latch. Confirm the circuit count and pitch match your receptacle — the 12-position, 2.50mm pitch dual-row layout is standard for the XAD series.
