JST PA series header, order code S16B-PASK-2(LF)(SN), 16 positions, single row, 2.00 mm pitch, 3 A, 250 V, tin-plated mating contacts, through-hole right-angle, kinked pin solder termination.
| Parameter | Value |
|---|---|
| Series | PA |
| Gender | Male Pin |
| Mounting type | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Locking Ramp |
| Voltage rating | 250V |
| Current rating | 3A |
| Operating temperature | -25°C~85°C |
| Contact material | Copper Alloy |
| Insulation color | Natural |
| Insulation height | 0.256\" (6.50mm) |
| Insulation material | Polybutylene Terephthalate (PBT), Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Board Guide |
| Shrouding | Shrouded - 4 Wall |
| Termination | Kinked Pin, Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 16 |
| Contact finish - post | Tin |
| Contact length - post | 0.134\" (3.40mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.126\" (3.20mm) |
The S16B-PASK-2(LF)(SN): A 4-wall shrouded housing with a locking ramp secures the header to the mating receptacle — the ramp latches audibly on engagement and resists vibration-induced disconnect. The housing is glass-filled PBT rated UL94 V-0 and operates from -25°C to 85°C.
The part is available in Bulk packaging. Request a quote for current pricing and lead time.
