Major League Electronics PC200S-05-S-04-T-TR-K-LF
MPNPC200S-05-S-04-T-TR-K-LF
Active
.200 Socket
$0.9300Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesPC200S-04
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | PC200S-04 |
| Type | Female Socket |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 7.9A |
| Operating temperature | -55°C ~ 105°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.368\" (9.35mm) |
| Insulation material | Liquid Crystal Polymer (LCP) |
| Material flammability rating | UL94 V-0 |
All specifications
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Bag |
| Features | Pick and Place |
| Termination | Solder |
| Contact shape | Square |
| Pitch | 0.200\" (5.08mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact finish - mating | Tin |
