2.00mm Pitch Shrouded Header for Automotive Signal Routing
The 0349126040: The 2.00mm pitch packs signal contacts tighter than the legacy 2.54mm standard, saving board real estate in ECU and sensor modules. Gold plating on the male blades ensures stable contact resistance over repeated mating cycles — a key requirement for field-serviceable automotive connectors where the harness may be disconnected for module replacement.
SMT Retention and Shrouded Protection
Insulation material is glass-filled syndiotactic polystyrene (SPS), rated UL94 V-0, suitable for equipment inside enclosures requiring flame retardancy.
Tape & Reel packaging suits automated pick-and-place assembly.
Mating Connector and Pinout
This header mates with Mini50 34912 series receptacle housings that accept 0.64mm blade-type terminals. Pinout is straightforward: one contact per position, all positions loaded. The rectangular male blades are arranged in a single row at 2.00mm pitch.
