Samtec Inc. — Pin Headers

Samtec Inc. Pin Headers — 10 part numbers with specifications and datasheets. Filter by key specs and request a quote on IC Source Direct.

Base Product Number
BBD-102 · BBD-103 · BBD-108 · BBD-110
Number of Positions
4 · 6 · 16 · 20
Insulation Height
0.211" (5.35mm) · 0.070" (1.78mm) · 0.085" (2.15mm) · 0.335" (8.51mm)
Contact Length - Mating
0.125" (3.18mm) · 0.105" (2.67mm) · 0.122" (3.10mm) · 0.065" (1.65mm)
Contact Length - Post
0.125" (3.18mm) · - · 0.107" (2.71mm) · 0.090" (2.29mm)
Contact Finish Thickness - Mating
20.0µin (0.51µm) · - · 10.0µin (0.25µm) · 3.00µin (0.076µm)
Current Rating (Amps)
- · 2.8A per Contact · 1.75A · 3A
Overall Contact Length
0.460" (11.68mm) · 0.300" (7.62mm) · 0.332" (8.43mm) · 0.585" (14.86mm)
