CLP-102-02-F-D
Samtec Inc.
Bulk24
Ref. price$0.8800
Lead time on requestGet quote ›
Samtec Inc. CLP1 Series
167 variants · Samtec Inc.
About the Samtec Inc. CLP1 Series
The Samtec Inc. CLP1 Series series groups 167 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common applications of -, contact finish - mating of Gold and contact length - post of -. Variants differ by connector type, contact finish - post and contact finish thickness - mating, so you can match the exact connector type your application requires using the selection guide below.
Select a variant by
- Connector type
- Receptacle · Receptacle, Bottom Entry
- Contact finish - post
- Gold · Tin
- Contact finish thickness - mating
- 3.00µin (0.076µm) · 3.90µin (0.099µm) · 10.0µin (0.25µm)
- Contact finish thickness - post
- - · 3.00µin (0.076µm) · 3.90µin (0.099µm)
- Features
- - · Board Guide
- Insulation height
- 0.084\" (2.14mm) · 0.090\" (2.29mm) · 0.135\" (3.43mm)
- Mounting type
- Surface Mount · Surface Mount, Right Angle
- Package
- Bag · Bulk · Tape & Reel (TR) Cut Tape (CT)
Shared specifications
- Applications
- -
- Contact finish - mating
- Gold
- Contact length - post
- -
- Contact material
- Phosphor Bronze
- Contact shape
- Square
- Current rating
- 3.3A per Contact
- Fastening type
- Push-Pull
- Gender
- Female Socket
- Ingress protection
- -
- Insulation color
- Black
- Insulation material
- Liquid Crystal Polymer (LCP)
- Mated stacking heights
- -
Variant comparison
| Parameter | CLP-102-02-F-D | CLP-102-02-F-D-BE | CLP-102-02-F-D-BE-TR | CLP-102-02-F-D-TR | CLP-102-02-G-D | CLP-102-02-G-D-BE |
|---|---|---|---|---|---|---|
| Connector type | Receptacle | Receptacle, Bottom Entry | Receptacle, Bottom Entry | Receptacle | Receptacle | Receptacle, Bottom Entry |
| Contact finish - post | Tin | Tin | Tin | Tin | Gold | Gold |
| Contact finish thickness - mating | 3.90µin (0.099µm) | 3.00µin (0.076µm) | 3.00µin (0.076µm) | 3.00µin (0.076µm) | 10.0µin (0.25µm) | 10.0µin (0.25µm) |
| Contact finish thickness - post | - | - | - | - | 3.90µin (0.099µm) | 3.00µin (0.076µm) |
| Features | - | - | - | - | - | - |
| Insulation height | 0.090\" (2.29mm) | 0.084\" (2.14mm) | 0.084\" (2.14mm) | 0.084\" (2.14mm) | 0.090\" (2.29mm) | 0.084\" (2.14mm) |
| Mounting type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package | Bulk | Bag | Tape & Reel (TR) Cut Tape (CT) | Tape & Reel (TR) Cut Tape (CT) | Bulk | Bag |
Request a quote on any Samtec Inc. CLP1 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
Frequently asked questions
- How do the Samtec Inc. CLP1 Series variants differ?
- Samtec Inc. CLP1 Series part numbers differ by connector type, contact finish - post, contact finish thickness - mating and contact finish thickness - post. Use the selection guide above to pick by connector type.
- How many Samtec Inc. CLP1 Series part numbers are listed?
- 167 Samtec Inc. CLP1 Series part numbers are listed, each with specifications and a datasheet where available.
- How do I get pricing and lead time for Samtec Inc. CLP1 Series?
- Request a quote (RFQ) for any Samtec Inc. CLP1 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.
