Through-hole right-angle USB-A with board lock
The 614004134726: Gold-plated contacts, a shielded brass shell, and a board lock secure the connector through wave solder — the UL94 V-0 white insulation suits equipment inside an enclosure.
Würth Elektronik 614004134726 USB-A Receptacle, 4-Pos
MPN614004134726
Active
Würth Elektronik WR-COM USB-A receptacle, order code 614004134726, 4 contacts, USB 2.0, 1.5 A, 30 VAC, gold-plated contacts, through-hole right-angle, solder termination, shielded, board lock.
$3.87Ref. price · indicative, final on quote
RoHSROHS3 Compliant
SeriesWR-COM
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — typically 7–15 days door-to-door
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | WR-COM |
| Mounting | Through Hole, Right Angle |
| Connector type | USB-A (USB TYPE-A) |
| Voltage - rated | 30VAC |
| Current rating | 1.5A |
| Positions | 4 |
| Mounting feature | Vertical |
| Operating temperature | -40°C ~ 105°C |
| Insulation color | White |
| Shell (Shielding material) | Brass |
| Material flammability rating | UL94 V-0 |
| Gender | Receptacle |
All specifications
| Parameter | Value |
|---|---|
| Package | Tray |
| Features | Board Lock |
| Shielding | Shielded |
| Termination | Solder |
| Mating cycles | 1500 |
| Contact finish | Gold |
| Specifications | USB 2.0 |
| Number of ports | 1 |
