Amphenol ICC (FCI) 54101-S0630LF BERGSTIK Header

MPN54101-S0630LF
Active

Amphenol ICC (FCI) BERGSTIK® header, order code 54101-S0630LF, 30 positions, single row, 0.100" (2.54mm) pitch, 3 A per contact, through hole, solder termination, tin-plated post, gold or GXT™ mating finish.

$1.5614Ref. price · indicative, final on quote
Amphenol 54101-S0630LF datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026

Specifications

54101-S0630LF key specifications
ParameterValue
SeriesBERGSTIK®
TypeMale Pin
MountingThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board

All specifications

54101-S0630LF additional specifications
ParameterValue
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions30
Contact finish - postTin
Contact length - post0.110\" (2.79mm)
Overall contact length0.440\" (11.18mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - post100.0µin (2.54µm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

30-position unshrouded header

The 54101-S0630LF is the 30-position member of the Amphenol ICC (FCI) BERGSTIK® unshrouded header line, a single-row board-to-board interconnect. Rated 3 A per contact, it carries a gold or GXT™ mating finish over 15.0µin (0.38µm) thickness and a tin-plated post for solder termination through hole.

Pitch and footprint fit

The 0.100" (2.54mm) pitch and single-row layout match the standard BERGSTIK® footprint — the 30 positions load all circuits, and the 0.110" (2.79mm) post length suits standard PCB thickness.

Frequently asked questions

What compliance documentation is available for 54101-S0630LF?

The header carries a UL94 V-0 flammability rating for the black insulation housing.
