Amphenol ICC (FCI) BERGSTIK® header, order code 54101-T0805LF, 5 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, tin-plated mating and post, through-hole, solder termination.
54101-T0805LF Amphenol ICC BERGSTIK Header, 5-Pos 2.54mm
MPN54101-T0805LF
Active
Amphenol ICC (FCI) BERGSTIK® header, order code 54101-T0805LF, 5 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, tin-plated mating and post, through-hole, solder termination.
$0.9700Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
All specifications
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 5 |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.450\" (11.43mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Product details
Frequently asked questions
What compliance documentation is available for the 54101-T0805LF?
RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) — confirm the latest revision at time of order.
