Through-hole unshrouded header, 36 positions
The 54101-T10-36 is the 36-position single-row member of the BERGSTIK series from Amphenol ICC (FCI), a through-hole unshrouded header with push-pull fastening.
54101-T10-36 Amphenol ICC (FCI) BERGSTIK Header, 36 Pos
MPN54101-T10-36
Active
Amphenol ICC (FCI) BERGSTIK header, order code 54101-T10-36, 36 positions, single row, 0.100" (2.54 mm) pitch, through-hole solder, tin-plated mating contacts, 3 A per contact, unshrouded.
$0.6044Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Contact length - post | 0.150\" (3.81mm) |
| Overall contact length | 0.480\" (12.19mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Product details
Frequently asked questions
What is the style of the 54101-T10-36?
The 54101-T10-36 is classified as a Board to Board style header.
What compliance documentation is available for the 54101-T10-36?
RoHS and REACH compliance documentation is available from the manufacturer.
